| PD42 W1: 42" Plasma Display | |
| Specifications | |
| Model | PD42W1 |
| Screen size | 42" (106cm) Diagonal 16:9 |
| Display pixels | 852(H) x 480(V) dots |
| Display area | 920(H) x518(V)mm (Pixel pitch: 1.08mm) |
| Display colors | 16,770,000 colors |
| Viewing angle | Vertical:=/- 80 degrees |
| Contrast | 550:1 |
| Brightness | 350 cd/sq. m (white peak) |
| Input terminals | BNC
x 1 for video, 4 pin mini DIN for S-video RCA x 5 for R, G, B, HD, VD/Y, Pb (Cb)/Pr (Cr) (for HDTV, etc) : fH 15.75/31.5/33.7kHz PC: VGA, SVGA, XGA, fH 31.5–50kHz, fv 50–70Hz |
| Input terminals | BNC
x 1 for video, 4 pin mini DIN for S-video RCA x % for R, G, B, HD, VD/Y, Pb (Cb), Pr (Cr) D-sub 15 pin (High Density) for PC (analog RGB) |
| Audio inputs | RCA x 2 (L/R) two sets, one set for Video, another for Component Video, M3 plug x 1 for PC |
| Audio output | 16 watts (8 watts x 2) for external speakers |
| Computer control | RS-232C via M2.5 3-pole connector |
| Size | 1030 (W) x 634 (H) x 89 (D) mm/40.6 (W) x 25.0 (H) x 3.5 (D) inches |
| Weight | 33 kg / 72.8 lbs |
| Power | AC 120V / 220-240V, 380 watts |
| Accessories | Infrared remotr controller, owner's manual |
