Professional DVD Player Model SD-B100 |
|
| Specifications | |
| General | |
| Model | SD-B100 |
| Disc | DVD, CD, Video CD |
| Video Format | NTSC, PAL |
| Dimensions | 212 (W) x 400(D) x 114(H)mm/8.35(W)x15.75(D)x4.49 (H) inches |
| Power | AC 100–240V, 25 watts |
| Output | |
| Video | 1Vp-p / 75 ohms BNCx1, RCA x 1 |
| S-Video | Y:1Vp-p, C: 0.286Vp-p / 75 ohms DIN mini4 pin x 1 |
| Audio | 200mV rms, L/R, RCA x 2 |
| External sync (Optional, functions only on DVD, not CD video) | |
| Composite sync input | 1 to 4Vp-p(10k / 75 ohms) BNC x 1 |
| Sync loop through | BNC x 1 |
| Extenal control | |
| Serial remote (RS-232C) | 1200/2400/9600/38400bps,
D-sub 9 pin x 2 (In/out) Three set of command protocols available Daisy chaining possible by internal switch (up to 31 sets) |
| "Parallel" remote | D-sub 15 pin |
| Infrared remote | Transmitter provided |
