| Models | P400LCU/P400LCE | P401LCU/P401LCE | |
| Type | 40-inch rear projection unit | ||
| Image device | 1 chip 1.6" LCD panel | ||
| Light source | 100-watt UHP lamp | ||
| Resolution | 800 x 600 dots | ||
| Brightness | 230 cd/sqm | ||
| Viewing angle | Horizontal: 150 degrees, Vertical: 60 degrees | ||
| Screen frame | 5mm (0.2inch) | ||
| Power | AC100-240V, 50/60Hz, 170W(170VA) | ||
| Dimensiuons | 813 (W) x 890(H) x 395(D) mm (32.0 x 35.0 x 15.6 inches) | ||
| Operating temperature | 0 to 35degrees celcius (41 to 95 degrees F) | ||
| Operating humidity | 20% to 80% RH, non condensing | ||
| Weight | 34kg | ||
|
Acceptable signal |
VGA, SVGA, XGA | VGA, SVGA, XGA and Video (NTSC/PAL) |
| Video input | Not available | BNC femalex1 |
| Video output | Not available | BNC femalex1 |
| RGB input for PC |
Mini D-sub 15 pin femalex2 HVC sync shall be at TTL level |
||||||||
| Internal splitter | For 2x2 use (2xmagnification only) | ||||||||
| External control | RS-232C, D-sub 9 pin femalex2 (IN and OUT) | ||||||||
| RemoteControl | Infrared remote/optional wired remote controller | ||||||||
| For wall, ceiling, stacked or 2x2 video wall installations, proper supporting brackets shall be used. | |||||||||
