Model
|
P410DLE/P410DLU
|
P411DLU
|
|
Type
|
41-inch
rear projection unit |
|
device
|
1
chip SVGA DLP |
|
Light
source
|
100-watt
UHP lanp |
|
Resolution
|
800
x 600 dots |
|
Brightness
|
350
cd/sq m |
|
Viewing
angle
|
Horizontal:
Min 150 deg, Vertical: Min 60 deg |
|
Screen
size
|
846
(W) x 631 (H) mm (including frame) |
|
Screen
frame
|
1.75mm
width |
|
Color
temperature
|
Selection
of 8000K and two user defined |
|
Power
|
AC
100-249V, 50/60Hz, 170W (170VA) |
|
Dimensions
|
846
(W) x 631 (H) x 1110(D) mm (33.3 x 24.8 x 43.7 inches) |
|
Operating
temperature
|
5
to 35 degrees C |
|
Operating
Humidity
|
30%
to 70% RH, non condensing |
|
Weight
|
68
kg |
| |
| Acceptable
signal |
Video
(NTSC/PAL). VGA, SVGA, XGA, HD-TV |
| Video
input |
Not
available |
BNC
female x 1 |
| Y/C
input |
Not
available |
BNC
female x2 |
| Y/Cb/Cr,
Y/Pb/Pr input |
Not
available |
BNC
female x3 |
RGB
input
(PC and component video) |
Mini
D-sub 15 pin female x 2
H, V, C sync shall be at TTL level |
| External
control |
RS-422,
DIN 8 pin x 2 (IN and OUT) |
| Digital
signal link |
TDMS,
DFP 20 pin x 2 (IN and OUT) |
| Remote
control |
By
optional wired remote controller via 3.5mm diameter terminal |
