| Display |
1.3"
Polysilicon TFT LCDx3 |
| Resolution |
SXGA
(1280x1024 compressed)/XGA (1024x768)/SVGA(800x600)/VGA(640x480)
|
| Brightness |
800
ANSI lumens |
| Projection
lens |
Manual
zoom and focus (F2.5-3.0/f+50-70mm) |
| Image
size |
22"
- 300" |
| Projection
distance |
3.6
to 39 feet (1.1 to 12m) |
| Lamp |
120W
UHP |
| Scanning
frequency |
fH15.63
– 91kHz.fv 50–85Hz |
| Audio
output |
Built-in
1.5 W monoaural speaker |
| Contrast |
1:300
(maximum) |
| Input
terminals |
1
RGB : D-sub 15 pins/1 audio for RGB : stereo mini jack/1
video : RCA and S-video (Priority) 1 audio for video
: RCA L&R |
| Output
terminals |
1
RGB : D-sub mini15 pins/1 audio : stero mini jack/1
camera : RCA pin (TLP571) |
| Power
source |
100-240V
AC, 50/60Hz |
| Power
consumption |
210W |
| External
dimensions (WxHxL) |
340x128x363
mm
13.4x5.0x14.3 inches
(without foot and lens) |
| Weight |
8.2kg
(18.1 lbs) |
| Document
camera |
•
1/3CCD.480.000pixels
• Resolution : 450 (H) 420 (V) lines minimum
• Adjustable focus and zoom
• Built-in floourescent light source
• Camera output : PAL
|
| |
|
|
|
|
|
| Diagonal
screen size |
Distance
between lens & screen |
Lens
height to screen bottom |
| (in
inches) |
MInimum
(Wide) (In meters or feet) |
Maximum
(Tele) (In meters or feet) |
(In
cm or Inches) |
| 60 |
2.3m
or 7.6' |
3.1m
or 10.2' |
14cm
or 5.5" |
| 100 |
3.8m
or 12.5' |
5.3m
or 17.4' |
23cm
or 9.1" |
| 150 |
5.7m
or 18.7' |
8.0m
or 26.2' |
34cm
or 13.4" |
