| Specifications
(Main unit) |
| Model |
TLP471 |
| LCD
Panel |
Pixels |
480,000
(800 x 600) x 3 |
| Form |
Size
0.9 inch TFT, aspect ration 4:3 |
| Projection
lens |
Manual
zoom focusing lens F 1.8~2.1, f 36~47 mm (x1.3) |
| Light
source |
150
W UHP lamp |
| Brightness |
1200
ANSI lumens |
| Resolution |
800
x 600 dots |
| Color
reproduction |
Full
color (16.7 million colors) |
| Contrast |
400:1 |
| Image
size |
23"~250" |
| Projection
distance |
3.6
to 33.1 feet (1.1 to 10.1 m) |
| Compatible
scanning frequency |
Horizontal
(kHz) |
15~93 |
| Vertical
(Hz) |
50~85 |
| Input
terminal |
Video |
1
line [RCA pin / S terminal (S terminal has priority)] |
| RGB |
1
line [D-sub 15 pin (Color difference signal switching
available)] |
| Audio |
video•RGB:
1 line each [RCA pin / stereo mini-jack] |
| Input
signal |
Video
signal |
NTSC,
PAL, SECAM |
| Color
difference signal |
Y/Pb/Pr(HDTV),
Y/Cb/Cr(DVD) |
| RGB
signal |
VGA,
SVGA, XGA/SXGA(compression), UXGA(compression) |
| Output
termial |
RGB |
1
line [D-sub 15 pin] |
| Audio |
1
line [Stereo mini-jack] |
| Control
input terminal |
RS-232C
[Mini-DIN] |
| Built-in
speaker |
1.0W
mono-aural speaker |
| Zoom-up
function |
1~4
times, four-step switching available |
| External
dimensions (WxDxH) |
318x87x288
mm
12.5x3.4x11.2 in
(w/o foot and lens) |
| Weight
(kg/lbs) |
4.4/9.7 |
| Power
consumption |
235W |
| Power
source |
100–240V
AC, 50/60Hz |
|
| Specifications
(document camera) (TLP671) |
| Image
pick-up device |
1/3
inch CCD 810k pixels |
| Resolution |
500
TV lines or more (horizontal resolution) |
| Camera
lens |
F=2.8
f=6.2mm Manual focusing |
