| Display |
0.9"
Polysilicon LCD x 3 |
| Input
signals |
SXGA
(1280 x 1024 compressed)VGA (640x480)
XGA (1024x768 compressed) NTSC/PAL/SECAM
SVGA (800x600) (Real) |
| Brightness |
1000
ANSI lumens |
| Projection
lens |
Manual
zomm & focus (F=1.8-2.1/f=36-47mm (x1.3)) |
| Image
size |
22"
- 250"
|
| Projection
distance |
3.6
to 32.8 feet (1.1 to 10m) |
| Lamp |
150W
UHP |
| Scanning
frequency |
fH
15-16 24-91 fv 50-85Hz |
| Audio
output |
Built-in
1W monoaural speaker |
| Contrast |
300:1 |
| Input
terminals |
1
RGB: D-sub 15 pins
Audio for RGB: stereo mini jack
1 video : RCA and S-video (Priority)
1 audio for video : RCS L&R
|
| Output
terminals |
1
RGB : D-sub mini 15 pins
1 Audio : stereo mini jack |
| Power
source |
100-240V
AC,50/60Hz |
| Power
consumption |
235W |
| External
dimensionss (WxHxL) |
318x87x288mm
12.5x3.4x11.2 inches
(without foot and lens)
|
| Weight |
4.4kg
(9.7 ibs) |
| Document
Camera |
1/3"
CCD 810,000 pixels
Resolution 500 TV lines
Adjustable focus lens
Built-in LED |
