| Technical
Specifications |
| |
|
Display
Technology
|
Technology
Resolution
Size
No.
of Pixels
|
High
Definition Light Valve (HDLV TM) x 3
1280
x 1024
1.3
inches diagonal
3,932,160
(1280 x 1024 x 3)
|
| Signal
frequency ranges |
Horizontal
(kHz)
Vertical
(Hz)
|
15-100
43-140
|
| Computer
compatibility |
Platforms
Input
interfaces
Resolutions
|
IBM-compatibility
PC (Wintel), Macintosh PC,IBM, SUN, HP, SGI, DEC workstations
13W3
x 1, HD15 x 1, 5xBNC x 1
VGA,
SVGA,XGA,SXGA,UXGA (PAN)
|
| Video
compatibility |
Input
Interfaces
Signal
Compatibility
Aspect
ratios
Display
modes
|
Composite
(RCA) x1, S-Video (4-DIN) x 1, Component* (Y, Pb, Pr) x 1
NTSC/NTSC4.43/PAL/PAL-N&M/CECAM/DVD
(525i,525p) DVD "squeeze" format/HDTV (16:9) (720p,
1035i, 1080i)
5:4,
4:3, 16:9
normal,
full, window
|
| Audio
in |
|
3
mini-DIN slots 1 for each computer interface)
RCA
x 2
|
| Lens
Configurations |
Lens
shift mechanism**
Projection
lens (Name [Projection ratio])
|
10:0
- 0:10, automatic keystone correction
Factory
option (Zoom [2.1-3.0], Wide [1.2:1], Super-wide [0.85:1])
|
| Brightness |
1600
ANSI Lumens |
| Contrast |
400:1 |
| Loopthrough
monitor out |
HD15
x 1 |
| Audio
out |
Built-in
2W stereo speakers x 2, RCA x 2 |
| Control
I/O |
RS-232C
(D-Sub 9 pin x 1), wireless and wired remote control |
| Light
source |
270-watt
metal halide |
| Lamp
Life |
1500
hrs, Half-Brightness |
| Operating
acoustic level |
39
dB
|
| Power
Supply |
AC
100 - 240V, 50 - 60 Hz) |
| Power
consumption |
420
watts |
| Operating
temperature |
36
- 99 Fahrenheit, o - 35 celsius |
| Weight
(W/O lens) |
28.6
Ibs, 13.0kg |
| Width |
13.4",
340mm |
| Depth |
17.5",
445mm |
| Height |
8.7",
220mm |
|
|
|
