Display |
Single-Chip
DMD (Digital Micromirror Device)
|
Resolution |
1024
x 768 with compression for 1280 x 1024 |
Brightness |
1000
ANSI Lumens |
Projection
Lamp |
120W
UHP (Ultra High Performance), User Replaceable |
Lamp
Life |
2000
Hours Typical |
Colour
Palette |
16.7
million colours (24bit) |
Aspect
Ratio |
4:3
or 16:9 |
Response
Time |
16
ms |
Contrast
Ratio |
450:1 |
Computer
Compatibility |
XGA:
50-90 Hz, SVGA: 50-120 Hz, SXGA: 50-70 Hz |
Video
Compatibility |
60
Hz: NTSC (M) (4.43), PAL (60) (M) 50 Hz: PAL (B/D/H/I/N),
NTSC (50), SECAM |
Projection
Lens |
Fixed
Focal Length Type |
Focal
Range |
1.5-7.5
m |
Uniformity |
85%
image center-to-corner |
Audio
system |
Built-in
2 watt loudspeaker |
Inputs |
PC,
Stereo Audio, RS232, Video, TV |
Outputs |
Stereo
Audio |
Mouse
Emulation |
Serial,
PS/2, ADB (Mac), USB |
Power
Input |
100-250V
AC |
Power
Consumption Typical |
170W,
Max 20W |
Operating
Temperature |
10-40
C (50-104 F) |
Dimensions |
254
x 208 x 78mm |
Weight |
2.25
kg |
