| Models |
P400LCU/P400LCE |
P401LCU/P401LCE |
| Type
|
40-inch
rear projection unit |
| Image
device |
1
chip 1.6" LCD panel |
| Light
source |
100-watt
UHP lamp |
| Resolution |
800
x 600 dots |
| Brightness |
230
cd/sqm |
| Viewing
angle |
Horizontal:
150 degrees, Vertical: 60 degrees |
| Screen
frame |
5mm
(0.2inch) |
| Power |
AC100-240V,
50/60Hz, 170W(170VA) |
| Dimensions |
813
(W) x 890(H) x 395(D) mm (32.0 x 35.0 x 15.6 inches) |
| Operating
temperature |
0
to 35degrees celcius (41 to 95 degrees F) |
| Operating
humidity |
20%
to 80% RH, non condensing |
| Weight |
34kg |
| Acceptable
signal |
VGA,
SVGA, XGA |
VGA,
SVGA, XGA and Video (NTSC/PAL) |
| Video
input |
Not
available |
BNC
femalex1 |
| Video
output |
Not
available |
BNC
femalex1 |
| RGB
input for PC |
Mini
D-sub 15 pin femalex2
HVC
sync shall be at TTL level
|
| Internal
splitter |
For
2x2 use (2xmagnification only) |
| External
control |
RS-232C,
D-sub 9 pin femalex2 (IN and OUT) |
| RemoteControl |
Infrared
remote/optional wired remote controller |
| For
wall, ceiling, stacked or 2x2 video wall installations, proper
supporting brackets shall be used. |
